HYRAX Model 50.13

Working height:

13,2 M

Horizontal reach:

10 M

Machine mass:

4.850 KG
Driving speed (transport mode): 2,8 KM/H

Models


Stage V diesel ATD

Plug-in diesel ATDe

100% Lithium ATE

The limitless powerhouse that keeps running.

This luxury machine really knows no limits. It is robust, simple and at the same time refined in every detail. The machine is a perfect combination of weight and innovation. It breaks all your limits. With 15 degrees of bi-leveling and flexible jib, no terrain is a limit. It is compact and lightweight, which makes it easy to carry on any cargo.

Heavy-Duty design

With this 5 tons total mass you defy every construction site and nevertheless 4 machines fit on only 1 semi-trailer.

Always leveled

The fully automatic leveling system corrects slopes of up to 15° and remains drivable at full height.

Max. working load 330 kg

Built for teamwork: 3 people, in addition to their equipment.

Work at 13,2 meters

Work stable at 13,2 meters working height and 10 meters of outreach.

HYRAX highlights

A HYRAX is particularly easy and quick to operate. It is the sum of all the little tricks which make the HYRAX. You simply set the HYRAX to your wishes. Without any complicated hassle.

Up to 13,2 metres high

Work higher, get more done

Reach sidways up to 10 metres

Work further with 200 kg at 10 m sideways

Lifting with up to 330 kilograms

Enough space for workers and material

Get up to height safely

Crush prevention above control panel

Easy to transport

Machine mass: 4.850 kg

Automatic bi-leveling

Up to 15º automatic bi-leveling.

Transport mode up to 2,8 km/h

At 13,2 metres at 1,4 km/h

Prepared for the future

Also available in all-electric versions

180° jib rotation

180° functional jib

360° slewing ring

360° continuous rotation

180° platform rotation

Flexible platform with 180° rotation

Made in Holland

100% Manufactured in the Netherlands

Specifications

Working height

13,2 m

Outreach

10 m

Driving at height

1,4 km/h at 13.2 m

Platform capacity

330 kg

Work platform rotation

180°

Continuous slewing ring

360°

Travel speed in transport mode

Till 2,8 km/h

Automatic bi-leveling

15° / 15°

L x W x H machine

4650 x 2200 x 2300 mm

Machine mass

4.850 kg

Ground clearance

350 mm

Want to know all the specifications and options?

Powerful and gorgeous.

These businesses went before you.

Schuler & Schuler AG

Schuler & Schuler AG

HYRAX dealer SCHULER & SCHULER AG is doing a great job for HYRAX in Switzerland. Schuler&Schuler serves the HYRAX...

read more
Sarl BMS

Sarl BMS

Here is the first HYRAX ATD 27.12 in France for SARL BMS! A lightweight and flexible machine, that allows access to the...

read more
Brinkers Montage

Brinkers Montage

HYRAX no. 2 for the men of Brinkers Montage from Enschede. This HYRAX ATD 27.12 is now fully involved in installing roof...

read more

The strength of HYRAX

The HYRAX brings together the wishes of discerning users. The key? You bring the HYRAX to any location quickly. The HYRAX can take you to any position. Take a look and discover the well thought out HYRAX.

Let us make a quotation

Interested in the MEWP of the future?

Let us convince you

Request a free demo at your location

Frequently asked questions

Is it possible to Finance the HYRAX?

Yes. We work together with several financing parties. In many cases this is also possible through your own bank. You choose whether you want to use financial or operating lease.

Where can I have my HYRAX serviced and inspected?
HYRAX offers different maintenance packages. You can have your machine maintained and tested by us, your regional dealer or service partner.
What are the warranty conditions for the HYRAX?
We offer: 1 year full manufacturer’s warranty and 2 years warranty on all constructional parts. The guarantee is offered on the condition that the machine is used for its intended purpose. Wearing parts such as tracks are not covered by the guarantee. HYRAX always uses the metal union conditions.
Does HYRAX also offer trailers?
HYRAX offers various custom-made 3500 kg trailers in all price ranges.
Is it possible to trade in my old MEWP?
Yes, we have good sales channels for used equipment. Therefore, we can always offer a fair current value for your used machines. We have good sales channels for used equipment. Therefore, we can always offer a fair current value for your used machines.
What safety standards does the HYRAX meet?
The HYRAX is built according to the EN280 norm and has a type approval from TÜV Netherlands.
How long can I work with the HYRAX ATE with a full battery?
A 20 kWh battery lasts approximately 1.5 working days. The larger 30 kWh battery is more than sufficient for 2 working days. Both calculations are based on average use.
